Page of 7 Go. Read through all instructions before beginning installation.
This is not a replacement for the ECU. This document is intended for use by qualified technicians. For more specific stock component identifition. To create the ideal map s we recommend using the optimal Z-AFM self-tuning module. Table of Contents.
Related Manuals for Ducati Desmosedici No related manuals. Page 3 2.
Install the supplied control unit mounting bracket to the right side engine cover securing it in place us- ing the two top cover bolts. Insert the Bazzaz control unit into the bracket.
Page 4 4.
Route the portion of the Bazzaz harness containing the power and neutral connectors toward the rear of the motorcycle along the right side. Locate the factory harness rear brake light switch power supply connector which can be found near the engine oil filler cap. Page 5 6. Secure the Bazzaz harness ground lug to a chassis ground.
Bazzaz recommends using the factory mount- ing bolt for the radiator mount attached to the left front cylinder head photo Bazzaz Ground Lug Installed Photo 10 7. Locate the throttle position sensor and disconnect the factory harness connector. Pull back the harness sheathing to expose the three wires of the factory harness and crimp on a supplied scotch lok connector onto the orange wire.
Reinstall the components removed in step one of these instructions. The Bazzaz controller is capable of storing two maps.
These maps can be selected through the use of a map select switch which can be mounted on the handlebar for easy access and can be purchased seper- ately. Comments to this Manuals Your Name:.
